What is Under Hardwood Floor? (5 Secrets Revealed!)

I once managed a flooring project in a 1920s New England home, where peeling hardwood floors revealed a fascinating story lying just beneath. That experience opened my eyes to how much goes on under hardwood floors—stuff most people don’t see or think about. If you’ve ever wondered, what is under hardwood floor?—I’m here to share some secrets that I’ve uncovered over years of installing and repairing hardwood flooring.

What Is Under Hardwood Floor?

At its core, the layer under a hardwood floor is often called the subfloor. But it’s not just one simple layer. Usually, there’s a combination of materials stacked beneath the beautiful wood planks you walk on. These layers work together to provide stability, insulation, and moisture protection.

Typically, the structure under hardwood flooring looks like this (from top to bottom):

• Hardwood flooring planks (usually 3/4 inch thick solid wood or 3/8 inch engineered wood)
• Underlayment (optional, depending on installation type)
• Subfloor (commonly plywood or oriented strand board—OSB)
• Joists (wood beams supporting the subfloor)
• Basement or crawl space (or concrete slab in some homes)

Each of these layers serves a specific purpose. The hardwood is what you see and enjoy. The underlayment adds cushioning and can reduce noise. The subfloor provides a flat, secure base for the hardwood. Joists hold everything up structurally. And below that, you’ll find the foundation of your home.

Breaking Down the Layers

Subfloor: Most homes built after the 1950s have plywood or OSB as subfloor material. Plywood is usually 3/4 inch thick sheets nailed or screwed to the joists. It costs about $30-$50 per sheet (4×8 feet), depending on quality and location. OSB is cheaper, around $15-$30 per sheet, but less moisture-resistant.

Underlayment: This layer is optional but common when installing engineered hardwood or floating floors. Underlayments can be foam, cork, or felt, typically 1/8 to 1/4 inch thick. They cost around $0.50 to $1.50 per square foot.

Joists: These are large wooden beams spaced about 16 inches apart on center. They’re usually 2×10 or 2×12 lumber, depending on span and load requirements.

Basement/Crawl Space: Below the joists and subfloor is a basement or crawl space, often with a concrete slab or dirt floor, which can affect moisture levels reaching the wood above.

Secret #1: The Subfloor Is the Unsung Hero of Flooring

Many homeowners focus so much on the hardwood itself that they forget the subfloor’s role. But I’ve learned from my projects that a solid subfloor is essential for a long-lasting hardwood floor.

For example, I worked on a mid-century home where the subfloor was just OSB sheets glued together but not properly fastened to the joists. Within two years, several boards in the hardwood started creaking and even buckling due to slight movement below.

A well-installed plywood subfloor, nailed every 6-8 inches along joists, prevents such issues. Also, thickness matters: too thin a subfloor (less than 5/8 inch) can flex underfoot and cause squeaks.

Subfloor Materials in Detail

Let’s talk about subfloor materials because that’s where things get interesting—and sometimes confusing.

Plywood: Made by layering thin sheets of wood veneer glued crosswise for strength, plywood is the most common subfloor material in North America. Thickness ranges from 1/2 inch to 3/4 inch; most floors use 3/4 inch for stability.

Plywood costs vary depending on grade and type:

• Standard plywood: $30-$40 per sheet
• Pressure-treated plywood (for moisture resistance): $50-$70 per sheet
• Specialty plywood (like marine grade): up to $100 per sheet

Plywood is sturdy but can swell if exposed to moisture for prolonged periods.

Oriented Strand Board (OSB): OSB is made from wood strands compressed with resin adhesives. It’s cheaper than plywood but less moisture resistant.

Prices range:

• OSB: $15-$30 per sheet
• Moisture-resistant OSB: up to $40 per sheet

OSB panels can swell if exposed to water but often perform well in dry environments.

Concrete Subfloors: In slab-on-grade or basement homes, concrete slabs sometimes serve as the base layer beneath hardwood floors (most often engineered wood). Concrete slabs require moisture mitigation before hardwood installation—usually via vapor barriers and moisture testing.

Why Subfloor Thickness Matters

Thickness affects rigidity and squeak prevention. Thin subfloors flex more underfoot, causing hardwood boards to move slightly and produce noise.

In my experience working with dozens of homes across different states:

• Homes with 3/4 inch plywood rarely had floor squeaks.
• Homes with thinner plywood (1/2 inch) or OSB had frequent squeaks without reinforcement.
• Adding an extra layer of plywood over existing subfloors is common when replacing flooring, adding about $2-$3 per square foot in labor and materials but significantly reducing squeaks.

Installation Techniques Affect Subfloor Performance

Nailing or screwing subfloor panels directly to joists every 6-8 inches is standard practice for stability. Using screws instead of nails helps prevent popping noises later.

In one renovation project in Seattle, we replaced old flooring and found nails loosely holding OSB subfloor panels. Replacing nails with screws eliminated squeaks entirely.

Secret #2: Moisture Barriers Are More Important Than You Think

Did you know that moisture coming up from below can ruin hardwood floors? A moisture barrier under the flooring protects wood from warping and mold.

In one project in humid Florida, no vapor barrier was installed over a concrete slab foundation before laying hardwood. Within months, the wood cupped badly due to moisture seeping up.

Common moisture barriers include:

• 6-mil polyethylene plastic sheets
• Specialized vapor barrier paint
• Foam underlayments with built-in vapor barriers

Using these costs about $0.10-$0.50 per square foot but saves thousands in damage repairs.

Moisture Testing Before Installation

Before laying hardwood over concrete slabs or in basements, it’s critical to test moisture levels using industry-standard methods:

• Calcium Chloride Test (ASTM F1869): Measures moisture vapor emission rate (MVER) through concrete slabs.
• Relative Humidity Test (ASTM F2170): Measures internal concrete slab humidity using probes drilled into slab.
• Moisture Meter Testing: Quick surface readings but less reliable for slabs.

For hardwood floors, acceptable moisture levels are:

If moisture is higher than these thresholds, installers must add vapor barriers or use alternative flooring.

Real-Life Example of Moisture Issues

I had a client in Houston who installed hardwood over a basement slab without testing moisture first. After six months, several planks warped and cupped due to moisture migration.

We remedied this by removing some boards, installing a 6-mil polyethylene vapor barrier beneath new plywood subflooring, then reinstalling engineered hardwood with a cork underlayment. The total repair cost was approximately $8,000—a steep price compared to upfront prevention costs around $500 for vapor barrier and testing.

Secret #3: The Type of Underlayment Changes Depending on Installation Method

Hardwood flooring installation methods vary: nail-down, glue-down, or floating. Each requires different underlayment types.

• Nail-down installation: Often used for solid hardwood over plywood subfloors; usually no underlayment needed.
• Glue-down installation: Common for engineered hardwood over concrete slabs; requires adhesive and sometimes cork or felt underlayment for sound dampening.
• Floating floors: Engineered hardwood that clicks together; requires foam or cork underlayment.

In one Boston condo project where we used floating engineered hardwood, we installed cork underlayment with a thickness of 3mm to reduce sound transfer between floors — crucial in multi-unit buildings.

Different Underlayment Materials

Here’s a quick breakdown of typical underlayments:

Why Choose Cork?

Cork reduces impact noise by up to 50%, making it ideal for apartments or multi-story homes where sound transfer is an issue. It’s also resistant to mold and mildew and sustainably harvested from cork oak bark.

I’ve installed cork underlayment in several New York City apartments where noise complaints were common—residents reported noticeably quieter living spaces post-installation.

Foam Underlayment Pros and Cons

Foam is inexpensive and easy to install but offers less soundproofing than cork or rubber. It also compresses over time if cheap quality foam is used.

On one job in Dallas where budget was tight, we used foam underlayment for floating engineered hardwood floors in a rental unit—it worked but didn’t reduce noise as much as hoped.

Secret #4: Sometimes There Are Surprises Beneath Your Floor

During renovations, I’ve found unexpected things beneath hardwood floors:

• Old newspapers used as insulation in a 1940s farmhouse
• Layers of previous flooring materials like linoleum or tile
• Structural damage like termite-eaten joists
• Uneven joists requiring shimming (small wooden wedges)

One memorable case involved a client who wanted to install hardwood over an old pine subfloor that was uneven by up to 1/2 inch across just a few feet. We had to sand and level carefully before installation.

The History Hidden Below Your Feet

Older homes especially may have several layers of flooring stacked over decades—think original wood planks topped by linoleum topped by carpet padding topped by carpet!

In my experience:

• Sometimes removing multiple layers is necessary before reaching a stable subfloor.
• Layers of old adhesive can make removal tricky.
• Discovering asbestos tiles beneath vinyl flooring requires professional handling and raises costs significantly ($5,000+ on average for abatement).

One time in Philadelphia, we uncovered four layers of flooring beneath carpet during demo—hardwood from the 1930s at bottom! We managed to refinish that original wood rather than install new flooring, saving the homeowner thousands and preserving character.

Structural Surprises

Termite damage or dry rot in joists often isn’t visible until floors are pulled up. Repairing joists can add thousands to project cost but is necessary for safety and floor longevity.

Uneven joists can cause squeaks and floor movement; shimming or sistering new joists are common fixes.

Secret #5: Soundproofing Can Be Hidden Under Hardwood Floors

If you live in an apartment or multi-story home, soundproofing is key. Underneath your hardwood floor, special acoustic underlayments can reduce impact noise by up to 50%.

I once recommended a rubber-based underlayment costing about $2 per square foot for a client in New York City who wanted quieter floors and insulation against cold drafts below.

Acoustic Underlayments Fact Sheet

How Does Sound Travel Through Floors?

Impact noise—like footsteps—is transmitted through hard surfaces like wood floors into rooms below. Adding dampening layers absorbs vibrations before they reach lower floors.

In multi-family buildings in cities like Chicago or Boston where noise codes are strictest, I always recommend acoustic underlayment as part of the installation package.

My Personal Experience: A Case Study

In a recent project involving an 800-square-foot living room remodel in Chicago:

• Existing flooring: old oak hardwood with failing adhesive.
• Subfloor: 3/4 inch plywood with water damage near windows.
• Solution: Removed old floor and damaged plywood.
• Installed new 3/4 inch tongue-and-groove plywood subfloor.
• Added 6-mil polyethylene vapor barrier due to basement humidity.
• Installed engineered hardwood with cork underlayment for sound reduction.

Total cost breakdown:

The whole job took about two weeks from start to finish. The result? Stable floors with zero squeaks and great soundproofing.

This project reinforced how essential each layer below the floorboard is—from proper subfloor prep to moisture control to soundproofing measures—to create a durable floor you enjoy every day.

What Happens If You Skip Layers?

I’ve seen cases where homeowners skip important steps like installing vapor barriers or reinforcing subfloors because of budget constraints or lack of knowledge.

Here’s what typically happens:

• Hardwood warps or cups due to moisture infiltration.
• Floors creak because subfloors move.
• Noise travels loudly between floors.
• Premature failure leads to costly repairs within few years.

Investing upfront in proper layering saves money long-term—think of it like building a sturdy foundation for your home’s beauty and comfort.

How To Check What’s Under Your Hardwood Floor?

Curious about what lies beneath your floors? Here are some easy ways to check without pulling everything up:

Visual Inspection at Floor Vents or Baseboards

Remove vent covers or baseboards carefully to peek underneath floor edges into crawl spaces or basements. You may spot subfloor material type and condition clues here.

Lift A Floorboard (If Possible)

If you have loose planks or during renovation phases, lifting one board shows what’s underneath—plywood? OSB? Concrete?

Use A Moisture Meter

Pin-type moisture meters can be pressed into gaps or edges of boards to estimate moisture levels below surface wood—helpful before refinishing floors.

Consult A Flooring Professional

If unsure or concerned about structural issues like rot or infestation, getting an expert evaluation prevents costly mistakes down the road.

Geographic Differences Affect Flooring Layers

Depending on where you live in the US—or beyond—the materials under your hardwood floor might differ because of climate and building styles:

For example:

In Florida’s humid climate, using untreated OSB without moisture barriers leads to rapid deterioration. In contrast, houses in dry Colorado may not require thick vapor barriers but still need soundproofing due to open space between joists.

How Do I Know Which Subfloor Is Best For My Project?

Choosing the right subfloor depends on several factors:

• Age and condition of existing floor structure
• Type of hardwood flooring planned
• Installation method
• Budget
• Local climate conditions

If you’re replacing an old floor in a historic home with uneven joists, adding an additional plywood layer might be necessary for stability.

If installing engineered hardwood directly over concrete slab basement floor, always include a vapor barrier and consider floating installation with foam underlayment.

Common Mistakes With Flooring Layers To Avoid

Here are mistakes I’ve seen that cause headaches later:

1. Skipping Moisture Testing Over Concrete Slabs: Leads to warped floors.
2. Using Too Thin Subfloor Material: Causes flexing and squeaks.
3. Not Fastening Subfloor Properly: Loose panels create noise.
4. Ignoring Soundproofing In Multi-Level Buildings: Results in noisy neighbors.
5. Installing Hardwood Directly On Concrete Without Vapor Barrier: Mold risk.
6. Neglecting To Remove Old Flooring Layers Properly: Adhesive residue affects new flooring adhesion.
7. Assuming All Underlayments Are The Same: Choosing wrong material affects comfort and durability.

Avoid these by consulting experienced contractors, testing moisture levels early, and budgeting for proper prep work.

How Long Does It Take To Prepare Flooring Layers?

Preparation time varies greatly depending on condition:

• Removing old flooring: Several hours to days for large spaces
• Inspecting and repairing subfloor: A day or more depending on damage
• Installing vapor barrier: A few hours for average room
• Laying new underlayment: Hours depending on material type

For a typical 1,000 square foot room renovation involving full replacement of all layers including subfloor replacement, expect approximately one to two weeks total including drying times for adhesives and sealers.

How Much Does It Cost To Prepare Under Hardwood Floors?

Costs depend on materials chosen and labor rates in your area; here are rough estimates:

Labor rates vary from $40-$75/hour regionally; specialized jobs like asbestos removal incur extra costs ($5k+).

Overall prep work can add up to approximately $3-$8 per square foot before hardwood flooring material costs are added.

What About Radiant Heating Systems Under Hardwood?

Radiant heating systems installed beneath subfloors add warmth but require special consideration:

• Engineered hardwood works better than solid wood due to dimensional stability.
• Subfloor must be level and free from debris.
• Vapor barriers compatible with heating systems must be used.

In one project in Colorado Springs installing radiant heat with engineered flooring over plywood subfloor cost roughly an additional $10-$15 per square foot but delivered excellent comfort during cold winters.

Final Thoughts

Understanding what’s under your hardwood floor can save you headaches down the road. Whether it’s choosing the right subfloor material,

adding moisture barriers,

or selecting proper underlayment for sound and comfort—

you’re building more than just a surface to walk on.

If you’re planning a flooring project soon,

don’t hesitate to inspect what’s beneath first.

Your future self will thank you!

Have you ever lifted a floorboard or pulled up some carpet to see what lies beneath? It’s like uncovering hidden layers of your home’s history—and knowing what’s down there puts you ahead when it comes time for repairs or upgrades.

Let me know if you want guidance on your specific floor setup—I’d be happy to help!

[End of article]
